Thiết bị bộ đàm ICOM 402/ 402S
Differences between IC-402 and IC-402S?
The IC-402S is identical to ICOMS award-winning IC-M402, but the IC-M402S does not accept an optional remote control mic __the “S” version is ideal for boaters who dont need a second helm radio station or the expense of the optional mic connection port.
Large 2-digit Ch with scrolling channel names
Look at the size of the LCD with large letters and numbers! The large, easy to see display has 27×43mm (11⁄16×15⁄8 in.) dimensions, so channel indications are maximized. 10-character channel names and all settings are displayed at the same time.
Force 5 Audio™
The front facing speaker offers loud crisp reception that is easy to hear, even over engine or wind noise.
Built-in DSC capability that meets RTCM SC101
The DSC watch function monitors Ch 70, while receiving another channel. It allows you to send a formatted distress message in an emergency. The position request function indicates a callers position. Up to 30 DSC IDs are memorized.
Submersible (1m depth for 30 minutes)
After each outing, spray the IC-M402/S with fresh water to remove any salt. By doing so, you will remove any mineral build-up, and extend the life of the raio. (Equivalent to JIS Grade 7; except cables)
Optional COMMANDMIC® (IC-M402 only)
Our COMMANDMIC® makes it convenient for using the IC-M402 from a separate cabin or tower. It allows you to remotely control all functions of the IC-M402 (except DSC operation). It offers its own large, easy to read LCD, is easy to hear and is also waterproof!
Upgraded features
- One touch access to Scan button on the front panel
- Impressive speaker audio
- Position indication in seconds accuracy
- NMEA input ERMC, GGA, GNS and GLL sentences
- Position report and position request functions
ADDITIONAL FEATURES
- Dualwatch and tri-watch functions for monitoring channel 16 and/or another call channel, while receiving on another channel
- Supplied remote function microphone for convenient channel and power selection
- NOAA weather channels with alert function
- Adjustable LCD backlighting and key illumination in 4 steps for nighttime operation
- Simple and easy tag scanning system
- Available in black or white
SPECIFICATIONS
TRANSMITTER
| GENERAL | |||
| Frequency coverage (Unit; MHz) | : Tx 156.025 – 157.425 Rx 156.050 – 163.275 |
||
| Usable channels | : All International, U.S.A.*and Canadian*channels; plus 10 weather*channels (* U.S.A. version only) | ||
| Type of emission | : 16K0G3E (FM), 16K0G2B (DSC) | ||
| Power supply requirement | : 13.8 V DC ±15% (neg. ground) | ||
| Current drain (at 13.8 V DC) |
|
||
| Operating temperature range | : -20°C to +60°C; -4°F to +140°F | ||
| Antenna connector | : SO-239 (50 ohm) | ||
| Dimensions (proj. not incl.) | : 153(W) × 67(H) × 141.6(D) mm 6 1/32(W)× 2 5/8(H)× 5 9/16(D)in |
||
| Weight | : 900g; 2lb | ||
| NMEA formats | : RMC, GGA, GNS, GLL | ||
| Output power (at 13.8 V DC) | : High 25 W Low 1 W |
||
| Modulation system; | : Variable reactance freq. modulation | ||
| Adjacent channel power | : 70 dB | ||
| Spurious emissions | : Less than -70 dBc | ||
| Residual modulation | : More than 40dB | ||
| RECEIVER | |||
| Receive system | : Double conversion superheterodyne | ||
| Intermediate freq. | : 1st 21.7MHz 2nd 450kHz |
||
| Sensitivity (at 12 dB SINAD) | : 0.22 µV typ. | ||
| Squelch sensitivity | : 0.22 µV | ||
| Adj. channel selectivity (wide/narrow) | : 70 dB | ||
| Intermodulation rejection | : 70 dB | ||
| Spurious response rejection | : 70 dB | ||
| Audio output power | : 4.5 W typ. at 10% distortion with a 4 ohm load | ||
Supplied accessories:
- Hand microphone, HM-141B/W
- DC power cable
- Mounting bracket kit
All stated specifications are subject to change without notice or obligation.
OPTIONS
- MB-69FLUSH MOUNT KIT
For flush-mounting the IC-M402 to a flat surface such as an instrument control panel. - MB-92DUST COVER
Protects the IC-M402 from dust and strong sunlight when the radio is not in use. - HM-141B/WHAND MICROPHONE
White and black are available. Same as supplied. - HM-157B/WREMOTE-CONTROL MICROPHONE (IC-M402 only)
Up to 21m (70ft) of freedom from the IC-M402 with two OPC-999 EXTENSION CABLES. Allows you to control all functions of the IC-M402 (except DSC operation).
Size (W×H×D): 63.5 × 125.0 × 31.4mm; 2 1/2× 4 29/32× 1 1/4in.
Weight (approx.;except cables): 150g ; 5.3oz
Supplied accessories : OPC-999EXTENSION CABLE FOR HM-127B/W (IC-M402 only)
6.1m (20ft) of extension cable for additional lengthening for use with COMMANDMIC®.- 6m (20ft) of cable
- Mic. hanger
- Mounting base for cable connector
Please note that the HM-127B/W is not compatible with the HM-134B.
-->COMMANDMIC is a trademark of Icom Inc.
